Single Row Thrust Cylindrical Roller Bearings
  • Single Row Thrust Cylindrical Roller Bearings

Single Row Thrust Cylindrical Roller Bearings

SYSTEM DESCRIPTION:

Single Row Thrust Cylindrical Roller Bearings

TECHNICAL DRAWING:

PREV：Thrust hard cylindrical roller bearingsNEXT：No next article

PRODUCT DETAILS:

Boundary dimensions (mm) load ratings(KN) Bearing No. Limiting speeds(r/min) Other dimensions(mm) Mass(kg)
d D B rsmin r1smin Cr Cor NU NJ NUP Grease Oil  Fw d2
20 42 12 0.6 0.3 10.5 9.5 NU1004 — — 13000 17000 25.5 — 0.09
  47 14 1 0.6 25.8 24 NU204E NJ204E NUP204E 12000 16000 26.5 29.7 0.117
  47 18 1 0.6 30.8 30 NU2204E NJ2204E NUP2204E 12000 16000 26.5 29.7 0.149
  52 15 1.1 0.6 29 25.5 NU304E NJ304E NUP304E 11000 15000 27.5 31.2 0.155
  52 21 1.1 0.6 39.2 37.5 NU2304E NJ2304E NUP2304E 10000 14000 27.5 29.7 0.216
25 47 12 0.6 0.3 11 10.2 NU1005 — — 11000 15000 30.5 — 0.1
  52 15 1 0.6 27.5 26.8 NU205E NJ205E NUP205E 11000 14000 31.5 34.7 0.14
  52 18 1 0.6 32.8 33.8 NU2205E NJ2205E NUP2205E 11000 14000 31.5 34.7 0.168
  62 17 1.1 1.1 38.5 35.8 NU305E NJ305E NUP305E 9000 12000 34 38.1 0.251
  62 24 1.1 1.1 53.2 54.5 NU2305E NJ2305E NUP2305E 9000 12000 34 38.1 0.355
30 55 13 1 0.6 13 12.8 NU1006 — — 9500 12000 36.5 — 0.12
  62 16 1 0.6 36 35.5 NU206E NJ206E NUP206E 8500 11000 37.5 41.3 0.214
  62 20 1 0.6 45.5 48 NU2206E NJ2206E NUP2206E 8500 11000 37.5 41.3 0.268
  72 19 1.1 1.1 49.2 48.2 NU306E NJ306E NUP306E 8000 10000 40.5 45 0.377
  72 27 1.1 1.1 70 75.5 NU2306E NJ2306E NUP2306E 8000 10000 40.5 45 0.538
  90 23 1.5 1.5 57.2 53 NU406 NJ406 NUP406 7000 9000 45 50.5 0.73
35 62 14 1 0.6 19.5 18.8 NU1007 — — 8500 11000 42 — 0.16
  72 17 1.1 0.6 46.5 48 NU207E NJ207E NUP207E 7500 9500 44 48.3 0.311
  72 23 1.1 0.6 57.5 63 NU2207E NJ2207E NUP2207E 7500 9500 44 48.3 0.414
  80 21 1.5 1.1 62 63.2 NU307E NJ307E NUP307E 7000 9000 46.2 51.1 0.501
  80 31 1.5 1.1 87.5 98.2 NU2307E NJ2307E NUP2307E 7000 9000 46.2 51.1 0.738
  100 25 1.5 1.5 70.8 68.2 NU407 NJ407 NUP407 6000 7500 53 59 0.94
40 68 15 1 0.6 21.2 22 NU1008 NJ1008 — 7500 9500 47 — 0.22
  80 18 1.1 1.1 51.5 53 NU208E NJ208E NUP208E 7000 9000 49.5 54.2 0.394
  80 23 1.1 1.1 67.5 75.2 NU2208E NJ2208E NUP2208E 7000 9000 49.5 54.2 0.507
  90 23 1.5 1.5 76.8 77.8 NU308E NJ308 NUP308E 6300 8000 52 57.7 0.68
  90 23 1.5 1.5 105 118 NU2308E NJ2308E NUP2308E 6300 8000 52 57.7 0.974
  110 27 2 2 90.5 89.8 NU408 NJ408 NUP408 5600 7000 58 64.8 1.25
45 75 16 1 0.6 23.2 23.8 NU1009 NJ1009 — 6500 8500 52.5 — 0.26
  85 19 1.1 1.1 58.5 63.8 NU209E NJ209E NUP209E 6300 8000 54.5 59.2 0.45
  85 23 1.1 1.1 71 82 NU2209E NJ2209E NUP2209E 6300 8000 54.5 59.2 0.55
  100 25 1.5 1.5 93 98 NU309E NJ309E NUP309E 5600 7000 58.5 64.7 0.93
  100 36 1.5 1.5 130 152 NU2309E NJ2309E NUP2309E 5600 7000 58.5 64.7 1.34
  120 29 2 2 102 100 NU409 NJ409 NUP409 5000 6300 64.5 71.8 1.8
50 80 16 1 0.6 25 27.5 NU1010 NJ1010 — 6300 8000 57.5 — —
  90 20 1.1 1.1 61.2 69.2 NU210E NJ210E NUP210E 6000 7500 59.5 64.2 0.505
  90 23 1.1 1.1 74.2 88.8 NU2210E NJ2210E NUP2210E 6000 7500 59.5 64.2 0.59
  110 27 2 2 105 112 NU310E NJ310E NUP310E 5300 6700 65 71.2 1.2
  110 40 2 2 155 185 NU2310E NJ2310E NUP2310E 5300 6700 65 71.2 1.79
  130 31 2.1 2.1 120 120 NU410 NJ410 NUP410 4800 6000 70.8 78.8 2.3
55 90 18 1.1 1 35.8 40 NU1011 NJ1011 — 5600 7000 64.5 — 0.45
  100 21 1.5 1.1 80.2 95.5 NU211E NJ211E NUP211E 5300 6700 66 70.9 0.68
  100 25 1.5 1.1 94.8 118 NU2211E NJ2211E NUP2211E 5300 6700 66 70.9 0.81
  120 29 2 2 128 138 NU311E NJ311E NUP311E 4800 6000 70.5 77.4 1.53
  120 43 2 2 190 228 NU2311E NJ2311E NUP2311E 4800 6000 70.5 77.4 2.28
  140 33 2.1 2.1 128 132 NU411 NJ411 NUP411 4300 5300 77.2 85.2 2.8
60 95 18 1.1 1 38.5 45 NU1012 NJ1012 — 5300 6700 69.5 — 0.48
  110 22 1.5 1.5 89.8 102 NU212E NJ212E NUP212E 5000 6300 72 77.7 0.86
  110 28 1.5 1.5 122 152 NU2212E NJ2212E NUP2212E 5000 6300 72 77.7 1.12
  130 31 2.1 2.1 142 155 NU312E NJ312E NUP312E 4500 5600 77 84.3 1.87
  130 46 2.1 2.1 212 260 NU2312E NJ2312E NUP2312E 4500 5600 77 84.3 2.81
  150 35 2.1 2.1 155 162 NU412 NJ412 NUP412 4000 5000 83 91.8 3.4
65 100 18 1.1 1 39 46.5 NU1013 NJ1013 — 4800 6000 74.5 — 0.51
  120 23 1.5 1.5 102 118 NU213E NJ213E NUP213E 4500 5600 78.5 84.6 1.08
  120 31 1.5 1.5 142 180 NU2213E NJ2213E NUP2213E 4500 5600 78.5 84.6 1.48
  140 33 2.1 2.1 170 188 NU313E NJ313E NUP313E 4000 5000 82.5 90.6 2.31
  140 48 2.1 2.1 235 285 NU2313E NJ2313E NUP2313E 4000 5000 82.5 90.6 3.34
  160 37 2.1 2.1 170 178 NU413 NJ413 NUP413 3800 4800 89.5 98.5 4
70 110 20 1.1 1 47.5 57 NU1014 NJ1014 — 4800 6000 80 — 0.71
  125 24 1.5 1.5 112 135 NU214E NJ214E NUP214E 4300 5300 83.5 89.6 1.2
  125 31 1.5 1.5 148 192 NU2214E NJ2214E NUP2214E 4300 5300 83.5 89.6 1.56
  150 35 2.1 2.1 195 220 NU314E NJ314E NUP314E 3800 4800 89 97.5 2.86
  150 51 2.1 2.1 260 320 NU2314E NJ2314E NUP2314E 3800 4800 89 97.5 4.1
  180 42 3 3 215 232 NU414 NJ414 NUP414 3400 4300 100 110 5.9
75 115 20 1.1 1 51.5 61.2 NU1015 NJ1015 — 4500 5600 85 — 0.74
  130 25 1.5 1.5 125 155 NU215E NJ215E NUP215E 4000 5000 88.5 94.6 1.32
  130 31 1.5 1.5 155 205 NU2215E NJ2215E NUP2215E 4000 5000 88.5 94.6 1.64
  160 37 2.1 2.1 228 260 NU315E NJ315E NUP315E 3600 4500 95 104 3.43
  160 55 2.1 2.1 245 308 NU2315E NJ2315E NUP2315E 3600 4500 95.5 104 5.4
  190 45 3 3 250 272 NU415 NJ415 NUP415 3200 4000 104.5 116 7.1
80 125 22 1.1 1 59.2 77.8 NU1016 NJ1016 — 4300 5300 91.5 — 1
  140 26 2 2 132 165 NU216E NJ216E NUP216E 3800 4800 95.3 101 1.58
  140 33 2 2 178 242 NU2216E NJ2216E NUP2216E 3800 4800 95.3 101 2.05
  170 39 2.1 2.1 245 282 NU316E NJ316E NUP316E 3400 4300 101 110 4.05
  170 58 2.1 2.1 258 328 NU2316 NJ2316 NUP2316 3400 4300 103 111 6.4
  200 48 3 3 285 315 NU416 NJ416 NUP416 3000 3800 110 122 8.3
85 130 22 1.1 1 64.5 81.6 NU1017 NJ1017 — 4000 5000 96.5 — 1.05
  150 28 2 2 158 192 NU217E NJ217E NUP217E 3600 4500 100.5 107 2
  150 36 2 2 205 272 NU2217E NJ2217E NUP2217E 3600 4500 100.5 107 2.58
  180 41 3 3 280 332 NU317E NJ317E NUP317E 3200 4000 108 117 4.82
  180 60 3 3 295 380 NU2317 NJ2317 NUP2317 3200 4000 108 117 7.4
  210 52 4 4 312 345 NU417 NJ417 NUP417 2800 3600 113 126 9.8
90 140 24 1.5 1.1 74 94.8 NU1018 NJ1018 — 3800 4800 103 — 1.36
  160 30 2 2 172 215 NU218E NJ218E NUP218E 3400 4300 107 114 2.44
  160 40 2 2 230 312 NU2218E NJ2218E NUP2218E 3400 4300 107 114 3.26
  190 43 3 3 298 348 NU318E NJ318E NUP318E 3000 3800 113.5 124 5.59
  190 64 3 3 310 395 NU2318 NJ2318 NUP2318 3000 3800 115 125 8.4
  225 54 4 4 352 392 NU418 NJ418 NUP418 2400 3200 123.5 137 11
95 145 24 1.5 1.1 75.5 98.5 NU1019 NJ1019 — 3600 4500 108 — 1.4
  170 32 2.1 2.1 208 262 NU219E NJ219E NUP219E 3200 4000 112.5 120 2.96
  170 43 2.1 2.1 275 368 NU2219E NJ2219E NUP2219E 3200 4000 112.5 120 3.97
