Bearing Unit No. | Bore Dia | Dimensions(mm) | Bearing No. | Housing No. | Weight | ||||||||||
in | mm | h | a | e | b | g | e | F | t | S | B | (kg) | |||
SUCPA201 | 12 | 30.2 | 76 | 52 | 40 | 11 | 62 | 13 | M10 3/8 |
12.7 | 31 | SUC201 | SPA203 | 0.6 | |
SUCPA201-8 | 1/2 | SUC201-8 | SPA203 | 0.6 | |||||||||||
SUCPA202 | 15 | SUC202 | SPA203 | 0.6 | |||||||||||
SUCPA202-10 | 5/8 | SUC202-10 | SPA203 | 0.6 | |||||||||||
SUCPA203 | 17 | SUC203 | SPA203 | 0.6 | |||||||||||
SUCPA203-11 | 11/28 | SUC203-11 | SPA203 | 0.6 | |||||||||||
SUCPA204 | 20 | 30.2 | 76 | 52 | 40 | 11 | 62 | 13 | M10 3/8 |
12.7 | 31 | SUC204 | SPA204 | 0.57 | |
SUCPA204-12 | 3/4 | SUC204-12 | SPA204 | 0.57 | |||||||||||
SUCPA205 | 25 | 36.5 | 84 | 56 | 38 | 12 | 72 | 15 | M10 3/8 |
14.3 | 34.1 | SUC205 | SPA205 | 0.81 | |
SUCPA205-14 | 7/8 | SUC205-14 | SPA205 | 0.81 | |||||||||||
SUCPA205-15 | 15/16 | SUC205-15 | SPA205 | 0.81 | |||||||||||
SUCPA205-16 | 1 | SUC205-16 | SPA205 | 0.81 | |||||||||||
SUCPA206 | 30 | 42.9 | 94 | 66 | 50 | 12 | 84 | 18 | M14 1/2 |
15.9 | 38.1 | SUC206 | SPA206 | 1.17 | |
SUCPA206-17 | 1-11/16 | SUC206-17 | SPA206 | 1.17 | |||||||||||
SUCPA206-18 | 1-1/8 | SUC206-18 | SPA206 | 1.17 | |||||||||||
SUCPA206-19 | 1-3/16 | SUC206-19 | SPA206 | 1.17 | |||||||||||
SUCPA206-20 | 1-1/4 | SUC206-20 | SPA206 | 1.17 | |||||||||||
SUCPA207 | 35 | 47.6 | 110 | 80 | 55 | 13 | 95 | 20 | M14 1/2 |
17.5 | 42.9 | SUC207 | SPA207 | 1.65 | |
SUCPA207-20 | 1-1/4 | SUC207-20 | SPA207 | 1.65 | |||||||||||
SUCPA207-21 | 15/16 | SUC207-21 | SPA207 | 1.65 | |||||||||||
SUCPA207-22 | 1-3/8 | SUC207-22 | SPA207 | 1.65 | |||||||||||
SUCPA207-23 | 1-7/16 | SUC207-23 | SPA207 | 1.65 | |||||||||||
SUCPA208 | 40 | 49.2 | 116 | 84 | 58 | 13 | 100 | 20 | M14 1/2 |
19 | 49.2 | SUC208 | SPA208 | 1.9 | |
SUCPA208-24 | 1-1/2 | SUC208-24 | SPA208 | 1.9 | |||||||||||
SUCPA208-25 | 1-9/16 | SUC208-25 | SPA208 | 1.9 | |||||||||||
SUCPA209 | 45 | 54.2 | 120 | 90 | 60 | 13 | 108 | 25 | M14 1/2 |
19 | 49.2 | SUC209 | SPA209 | 2.17 | |
SUCPA209-26 | 1-5/8 | SUC209-26 | SPA209 | 2.17 | |||||||||||
SUCPA209-27 | 1-11/16 | SUC209-27 | SPA209 | 2.17 | |||||||||||
SUCPA209-28 | 1-3/4 | SUC209-28 | SPA209 | 2.17 | |||||||||||
SUCPA210 | 50 | 57.2 | 130 | 94 | 64 | 14 | 116 | 25 | M16 5/8 |
19 | 51.6 | SUC210 | SPA210 | 2.73 | |
SUCPA210-30 | 1-7/8 | SUC210-30 | SPA210 | 2.73 | |||||||||||
SUCPA210-31 | 1-15/16 | SUC210-31 | SPA210 | 2.73 | |||||||||||
SUCPA211 | 55 | 63.5 | 140 | 104 | 66 | 14 | 125 | 25 | M16 5/8 |
22.2 | 55.6 | SUC211 | SPA211 | 3.37 | |
SUCPA211-32 | 2 | SUC211-32 | SPA211 | 3.37 | |||||||||||
SUCPA211-34 | 2-1/8 | SUC211-34 | SPA211 | 3.37 | |||||||||||
SUCPA211-35 | 2-3/16 | SUC211-35 | SPA211 | 3.37 | |||||||||||
SUCPA212 | 60 | 69.9 | 150 | 114 | 68 | 15 | 138 | 25 | M16 5/8 |
25.4 | 65.1 | SUC212 | SPA212 | 4.37 | |
SUCPA212-36 | 2-1/4 | SUC212-36 | SPA212 | 4.37 | |||||||||||
SUCPA212-38 | 2-3/8 | SUC212-38 | SPA212 | 4.37 | |||||||||||
SUCPA212-39 | 2-7/16 | SUC212-39 | SPA212 | 4.37 | |||||||||||
SUCPA213 | 65 | 76.2 | 160 | 124 | 70 | 15 | 150 | 25 | M16 5/8 |
25.4 | 65.1 | SUC213 | SPA213 | 5.36 | |
SUCPA213-40 | 2-1/2 | SUC213-40 | SPA213 | 5.36 | |||||||||||
SUCPA213-41 | 2-9/16 | SUC213-41 | SPA213 | 5.36 |
AISI 440C Material:
Higher resistance to rust and corrosion than 52100 chrome bearing steel, Please note that AISI 440C will have magnetic properties.
Chemical Composition: C:0.95-1.20, Si≤1.00,Mn≤1.00, P≤0.04, S≤0.03, Cr:16.0-18.0,Mo:≤0.75
AISI 304 Material:
AISI 304 stainless steel, widely used as corrosion- and heat-resistant steel and also as nonmagnetic steel, is suitable in corrosive environments where
AISI 440C stainless steel can not be used.
Chemical Composition: C≤0.08, Si≤0.75,Mn≤2.00, P:0.045, S:0.03, Cr:18.0-20.0,Mo:8.0-10.5,Ni≤0.10
AISI 316L Material:
316L stainless which provides corrosion resistance when compared to conventional steel and 440 stainless bearings.
316L Stainless is the standard molybdenum-bearing stainless steel. The molybdenum gives 316 better overall corrosion resistant properties than Grade 304,
particularly higher resistance to pitting and crevice corrosion in chloride environments.
Chemical Composition: C≤0.03, Si≤1.00,Mn≤2.00, P≤0.045, S≤0.03, Cr:16.0-18.0,Mo:2.0-3.0, Ni:10.0-14.0
Packing
Tube packing, single box packing or other industrial packing are all available.Special requirements should be mentioned in the order
Our own NSJ package is as below
